Diameter Sizes of Oil Filled, Rotary Heat Press Drums and Productivity Rates

Monday, September 25, 2017 :: Blog

The diameter of an industrial style rotary heat press drum will relate to how much productivity you can run per hour through the press. In the case of the Eastsign oil filled rotary heat press drums, the standard size of the industrial units are 16.5” diameter, or 420mm. Generally, the heat press temperature runs at around 400 degrees F and the time in the belt is about 30 seconds. All of this is adjustable and can be varied for different materials and uses, such as heat fixation or bonding of commercial materials.

Drum sizes available are 420mm, 600mm, 800mm and 1 meter. There is also a 1.5 meter size in the HS or High Speed model for extremely large volume requirements. We work closely with you to select the right size heat presses for your current and future production needs.

The USAheatpress line of Eastsign heat presses are quite affordable and will generally be about half the cost of the more expensive Monti Antonio, Kleverik, AIT, Practix or Royal Sovereign. As a plus, USAheatpress stocks inventory in the US on the heat presses and also has a US parts inventory!

Here are some basic starting rates of production in respect to drum sizes;

420mm or 16.5” drum size yields about 4.9 feet/min or 295.3 feet per hour running 1.5 m/min.
600mm or 23.6” drum size yields about 6.56 feet/min or 394 feet per hour running 2 m/min.
800mm or 31.5” drum size yields about 9.84 feet/min or 591 feet per hour running 3 m/min.
1 meter or 39.37” drum size yields about 14.76 feet/min or 886 feet per hour running 4.5 m/min.

A detailed chart with drum sizes and drum or press width is available on our web site or by contacting us. SOT heat presses start at 44” wide and the larger MOT, RTR go from 68” to 100” and the roll to roll or RTR versions run up to 130” or 3.2 meter wide.

As consultants and providers to the dye sublimation industry, Digital 2 You has the expertise in guiding you through the 12-18 month learning curve and process of taking production dye sublimation to a profitable level. By providing the right dye sub wide format printers and matching them to the right heat press solutions, we can offer your group a turn key equipment package to meet your production needs. Digital 2 You and USAheatpress are the exclusive importers of the Eastsign SOT versions of heat presses and offer US stocking of inventory for prompt shipment, installation & training options, parts stocking in the US and a network of dealers to support your local needs. For more information on Epson wide format dye sublimation printers & Eastsign SOT, MOT, or RTR rotary heat presses, please contact Dennis Halley at 720-480-5196 or visit our web sites;
